Well Completion Strategies for Water Well Drilling Rig in Complex Rock

News 13 Views
Water well drilling rigs need scientific strategies in complex hardness rock formations.water well drilling rig



  1. When drilling through sand (f=1) into limestone (f=6), switch from mud to casing support. Casing goes 3m beyond sand layer bottom to prevent collapse.
  2. In alternating soft-hard rocks (shale-sandstone), use “graded drilling”. First drill with Φ130mm bit, then expand with Φ200mm after finding interfaces. Keep mud density 1.2-1.3 for slag carrying and pressure balance.
  3. For quartzite interlayers (f>10), use diamond bits. Follow “light pressure, slow rotation”: 8-10kN feed pressure, ≤400r/min. A water well drilling rig injects 50L lubricant hourly to reduce friction and extend bit life.
